R3 Hydraulic Hose


R3 Hydraulic Hose

Specifications

Application Hydraulic System With Petroleum Or Water Based Fluid & For Fuel And Lubricating Oils.
Lining Black Oil Resistant Synthetic Rubber Compound.
Reinforcement Two Braid Of High Tenacity Textile Yarn.
Cover Synthetic Rubber Compound Resistant To Weather, Ageing And Abrasion.
Temperature Service Temperature - 40°C To +100°C

With the support of diligent and skilled workforce, we are distinguished as one of the well-equipped organization engaged in manufacturing and supplying high quality R3 Hydraulic Hose. The R3 Hydraulic Hoses that we offer are precisely designed and finished by the team of experts. These are manufactured using the high quality raw material and give trouble free performance to the user. To meet the specific requirements of our clients, our hoses are available with unique features.


Yes! I am interested


Specifications

Nominal Bore Mean O. D. Maximum Working Pressure Minimum Burst Pressure
INCH MM MM PSI BAR PSI BAR
1/4” 6.00 15.00 1250 86 5000 345
5/16” 8.00 18.00 1200 83 4800 331
3/8” 10.00 19.80 1125 78 4500 310
1/2” 12.50 23.50 1000 69 4000 276
5/8” 15.90 27.50 875 60 3500 241
3/4” 20.00 31.50 750 52 3000 207
1” 25.00 37.50 565 39 2250 155
